4系列弹簧储能起动机 (适配排量10-13升的发动机)
重庆双奥/Cqstart 4系列弹簧储能起动机，适配10-13升排量的柴油机，广泛用于船用发电机。
产品详情
适配发动机型号
- 潍柴WP12
- 潍柴WD618
- 道依茨BF6M1015
- 河柴TBD234 V12
4系列弹簧起动器的特点
- 适用于排量10-13升的发动机
- 终身免维护，使用高级润滑脂，减少维护成本和时间。
- 操作方便，可以在30秒内完成一个循环。
弹簧储能起动机规格 操作视频
| Cqstart弹簧储能起动机 | 4系列 | |
| HDP2 | ||
| 安装法兰 | SAE#标准结构号 | 1, 2, 3 |
| 柴油机排量 | 升(L) / 每缸 & 最多气缸数 | 2.1 & 6 |
| 1.7 & 8 | ||
| 1.5 &12 | ||
| 驱动力矩（推荐） | Nm | 126 |
| 最大盘动力矩 | Nm | 100 |
| 重量 | Kg | 23 |
| 盘动圈数 | 圈 | 2+13 |
重庆双奥/Cqstart为满足各种柴油机的不同需求，提供SAE全系标准接口，也可以根据需求定制化开发。
数百种特种合金齿轮方案，坚固耐用，适配不同的应用。多种模数及齿数，压力角，适配不同机型。
Product Features
1. Product Function of Cqstart Spring Starter :
The starter can compress the springs and store high energy within the unit, then release energy rapidly to start the engine.
It only needs hand cranking and releasing.
2. Typical Features of Cqstart Spring Starter :
a. Adaptability (Adapt to harsh working conditions, including the conditions with spark, chemistry and wet.)
b. Safety (It is a type of mechanical starter, which can be directly operated by people.)
c. Simple and Complete Structure (Independent hand-cranking working system, with no electricity, gas or other energy systems.)
d. Swift (Easy to operate, and it can release the energy rapidly.)
e. Maintenance-free (Resistant high/low temperature, corrosion resistance. There is no maintenance cost.)
f. Reliability (Reasonable design, mature technology, high-quality material, strict control.)
g. Preventor (Prevent misoperations on dual motor engines.)
